Design of the Student House in Lviv

Yevhen Nahirnyi

  • Design of the Student House in Lviv 2
  • Design of the Student House in Lviv 3
Basic information
ID
ФНаг-Лев-Арх-2557
Author
Yevhen Nahirnyi
Name
Design of the Student House in Lviv
Technique
drawing
Material
paper Indian ink
Dimensions (height x width, cm)
48 x 64
Additionally
Genre
architecture
Provenance
Nahirnyi-Lev Fund
Place
Lviv (Ukraine)
Information about author
Author
Yevhen Nahirnyi
Country
Austro-Hungarian Empire, the Ukrainian SSR, now Ukraine
Object description
The drawing shows a project of a building for students, which includes a dormitory (3-4 floors), a dining room (in the basement), a study room with a library, and a museum (1-2 floors). It is a separate four-storey building with a basement, occupying almost the entire rectangular plot. The layout is symmetrical, with many oval and rounded shapes. The centrepiece of the plan is a large oval foyer on the ground floor, above which are a two-storey library and two lecture theatres. A smaller separate foyer was designed for female students ("for the ladies"). Yevhen Nahirnyi probably made this sketch of the building, but the idea was not realised.
Inscriptions
Title in ink: "Design of the Student House in Lviv"; below, an ink inscription: "Second Floor"; functional purpose of each room is signed; inscription in ink to the right of the drawing: "Project Arch. / signature / Yevhen Nahirnyi"; to the left of the drawing is an ink inscription: "Scale 1:200".
